OBO Bettermann A6 Junction Box - Empty

    Categories

    OBO Bettermann A6 Junction Box - Empty
    Code: 2000001

    Shop the OBO Junction Box A 6 for top-quality electrical connections. Perfect for commercial and residential applications. Durable and reliable design.

    Selling Units: Each
    Loading...


    Product Description

    OBO Junction Box A 6

    Compact, durable junction box for indoor and outdoor applications.

    Made from tough PVC with IP55 protection and a clamping cover for secure closure.

    Features


    • Protection Rating: IP55
    • Nominal Voltage: 690 V
    • Nominal Cross-Section: 2.5 mm²
    • Cable Entries: 6 x Ø5–14 mm , 4 x Ø5–9 mm
    • Cover Type: Clamping cover
    • External Dimensions: 80 x 43 x 36 mm
    • Clear Internal Dimensions: 69 x 32 x 30 mm
    • Order in multiples of: 10
    • Price per: Unit

    Ideal for reliable, weatherproof electrical connections.



    Technical Specifications
    Type of entry Cable For Ex zone gas Without
    Halogen-free yes Measured insulation voltage Vi 690 V
    Mounting type Wall/ceiling mounting No. of entries 10
    Nominal cross-section, min. 2,5 mm² Nominal voltage 690 V
    Protection rating IP55 Sealable no
    Shape Square For Ex zone dust Without
    Type of housing penetration Pre-marking Type of insertion Cable
    Weatherproof no with lid yes
    With screening no Junction box cover version Blanking lid
    Max. Conductor cross-section 2,5 mm² 4 entries for cable diameter 5‒9 mm
    Transparent lid no Clear internal dimensions 69x32x30 mm
    Dimension 80x43x34 Length 80 mm
    Material Polyethylene CO₂ Footprint (GWP) Cradle-to-Gate 0,1028 kg CO₂e / 1 Piece
    Height 36 mm Maintain electrical functions Without
    Width 43 mm Permitted temperature range, max. 45 °C
    Permitted temperature range, min. -5 °C Colour Light grey; RAL 7035
    Cover Not transparent Cover fastening Locking
    Entries 6 entries for cable diameter 5‒14 mm Entry from rear no
    Equipment Without Expandable yes
    Explosion-tested version no Flame-resistant acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C
    For Ex zone Without
